The JL3 Series from Clearstone Technologies is ideal for spot curing or digital printing applications. The JL3-OEM series are small LED heads designed for integration into larger systems.

Product Details


JL3 Series UV LED

  • Air cooled built in fan, removable air filter
  • Dimensions: 111x70x118mm3, (4.37×2.76×4.65in3) L x W x H, Weight: 950gm (2 lb 2 oz)
  • Dimensions with lens = 111x70x128mm3 , (4.37×2.8×5.04in3) L x W x H
  • Mounting on four sides (M6 and M4 threads), Cable: 2 m (6 ft) integrated with LED head

Features and Options

  • Available Wavelengths: 365, 385, 395-410, 455 nm
  • Uses one or two channels of CF2000
  • Weight: 950gm
  • Dimensions: 117x70x118mm3
  • Numerous LED arrangements and lens options including lens array

Need to integrate a small LED solution, but don’t require a power supply? With the JL3-OEM series draw power and control the device from your own equipment.

LED Characteristics

  • Instant Turn On
  • High Reliability
  • Safe Low Voltage
  • Ozone Free
  • No Mercury
  • No Infrared Heating

JL3-Series Data Sheet (version 02.22.2017)

Do you need help deciding the best solution for your business?

Clearstone Technologies offers the option to demo our equipment in order to judge if our products will satisfy your requirements. Contact us for more information.
